Type

45FT 3 Axles Skeleton Semi-Trailer

Parameter

Dimension(mm)

length×width×height:13950×2480×1540mm

King Pin Setting(mm)

1100

Fifth Wheel Height(mm)

The height will be adjusted according to the tractor specification

Axle Space(mm)

8500+1310+1310

Tare Weight（kg）

6200

Payload （kg）

33800

Fabric

Main Beam(mm)

500, submerged arc welding Q345B

Flange and Web(mm)

14/6/16

Lock

10 retractable locks

Paint

primer + top coat

OEM

Landing Gear

FUWA 19”

Kingpin

50＃，FUWA

Brake System

30/30 type on rear two axles with brake valve

ABS

No

Suspension

Mechanical suspension with 8 leaf spring

Axle

FUWA 13T. Number: 3

Tire

12R22.5-18PR, Number:12

Rim

9.0*22.5 Number:12

Tool box

1 set on right side, 1m, steel

Spare Tire Carrier

equipped 2 sets per chassis

Color

According to customer’s requirements

Others

l   “LONG VEHICLE” sign on the rear end.

l   LED lights，equip side turn light.

l   Main beam: stick “JUPITER” logo

l   Mud flap: stick “JUPITER ”

l   Nameplate: English model
